Original file(3,024 × 4,032 pixels, file size: 2.08 MB, MIME type: image/jpeg)

A Simplex 35 PR-1014 configured for use with a platter system in a multiplex. The reel arms are bypassed by guide rollers. There are two guide rollers on the upper arm, one for directing film to the from the platter system pictured behind the projector and to guide film in from another projector when the two are interlocked. A Kelmar cue detector/failsafe is mounted beneath the soundhead.
